Frame with Fork Size
S, XL, XS, L, M, ML
-
Frame with Fork
900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
-
Fork Size
S, XL, XS, L, M, ML
-
Fork
Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100 mm chamfered thru axle
-
Weight
ML - 7.05 kg/15.55 lb (with TLR sealant, no tubes, no bottles/cages)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
-
Battery Size
S, XL, XS, L, M, ML
-
Battery
Shimano BT-DN300
-
Charger Size
S, XL, XS, L, M, ML
-
Charger
Charging cable included
-
Shifter Size
S, XL, XS, L, M, ML
-
Shifter
Shimano Dura-Ace R9270 Di2, 12 speed
-
Front Derailleur Size
S, XL, XS, L, M, ML
-
Front Derailleur
Shimano Dura-Ace R9250 Di2, braze-on, down swing
-
Rear Derailleur Size
S, XL, XS, L, M, ML
-
Rear Derailleur
Shimano Dura-Ace R9250 Di2, 34T max cog
-
Crank Size S, XS
Shimano Dura-Ace R9200, 52/36, 165 mm length
-
Crank Size L, M, ML
Shimano Dura-Ace R9200, 52/36, 170 mm length
-
Crank Size XL, L, ML
Shimano Dura-Ace R9200, 52/36, 172.5 mm length
-
Crank Size XL
Shimano Dura-Ace R9200, 52/36, 175 mm length
-
Bottom Bracket Size
S, XL, XS, L, M, ML
-
Bottom Bracket
Praxis, T47 threaded, internal bearing
-
Cassette Size
S, XL, XS, L, M, ML
-
Cassette
Shimano Dura-Ace R9200, 11-30, 12-speed
-
Chain Size
S, XL, XS, L, M, ML
-
Chain
Shimano Dura-Ace/XTR M9100, 12-speed
-
Max. chainring size
1x: 54T, 2x: 56/43
-
Front Wheel Size
S, XL, XS, L, M, ML
-
Front Wheel
Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm rim depth, 100x12 mm thru axle
-
Rear Wheel Size
S, XL, XS, L, M, ML
-
Rear Wheel
Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm rim depth, Shimano 11/12 freehub, 142x12 mm thru axle
-
Front Skewer Size
S, XL, XS, L, M, ML
-
Front Skewer
Bontrager Switch chamfered thru axle
-
Rear Skewer Size
S, XL, XS, L, M, ML
-
Rear Skewer
Bontrager Switch chamfered thru axle, removable lever
-
Tire Size S, XL, XS, L, M, ML
Bontrager Aeolus RSL RD, Tubeless-Ready, cotton construction, aramid bead, 170 tpi, 700x28 mm
-
Tire Size S, XL, XS, L, M, ML
Pirelli P Zero Race, 120 tpi, tubeless-compatible, 700x28 mm
-
Tire Part Size
S, XL, XS, L, M, ML
-
Tire Part
Bontrager TLR sealant, 180 ml/6 oz
-
Tube Size
S, XL, XS, L, M, ML
-
Tube
Pirelli P Zero SmarTube, TPU
-
Max tyre size
32 mm (as measured, see manual for details)
-
Saddle Size
S, XS
-
Saddle
Aeolus RSL, carbon rails, 155 mm width
-
Saddle Size
S, XL, XS, L, M, ML
-
Saddle
Aeolus RSL, carbon rails, 145 mm width
-
Seatpost Size
S, XL, XS, L, M, ML
-
Seatpost
Madone aero carbon seat post, 0 mm offset, short length
-
Integrated Bar Stem Size XS
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 35 cm control width, 38 cm drop width, 80 mm stem length
-
Integrated Bar Stem Size S
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm drop width, 90 mm stem length
-
Integrated Bar Stem Size M
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 90 mm stem length
-
Integrated Bar Stem Size L, ML
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 100 mm stem length
-
Integrated Bar Stem Size XL
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 110 mm stem length
-
Handlebar Tape Size
S, XL, XS, L, M, ML
-
Handlebar Tape
Trek EcoTack
-
Brake Size
S, XL, XS, L, M, ML
-
Brake
Shimano Dura-Ace hydraulic disc, flat mount
-
Brake Rotor Size
S, XL, XS, L, M, ML
-
Brake Rotor
Shimano CL900, CentreLock, 160 mm
-
Rotor size
Max brake rotor sizes: 180 mm front, 160 mm rear
