Orbea ORCA M20iLTD PWR Road Bike in Spark Silver/Titain Grey Gloss

Season:2026

Brand:Orbea

Code:T114TTCCA7

The feeling of a bike this light and efficient is unbeatable.

This instant acceleration, vibration absorption, and responsive handling come from a frame which knows where it needs to be light and where it needs to be stiff.

Features:

  • OMX Carbon: The top-level OMX frame has fewer pieces of carbon, meaning fewer overlaps and less weight. It takes much more effort to lay out the carbon, but the result is a saving of almost 300g with no change in the rigidity.
  • Size tuned stiffness: Orbea alters the carbon layup for each frame size to ensure every Orca feels the same. These are the small details you notice when you ride.
  • Powerspine: The lower spine of the frame handles the large majority of torsional and lateral loads.
  • ICR Plus: Internal Cable Routing is carefully guided along the best path under the stem and through the head tube, with no rub or rattle, and is optimized for both traditional and electronic shifting systems.
  • 32 mm Tire Clearance: Modern road riders have discovered the advantages of bigger tires on rougher surfaces.
Technical Information
  • Frame
    Orbea Orca carbon OMX 2024, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing.
  • Fork
    Orbea Orca OMX ICR 2024, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1.
  • Steerer tube
    FSA 1-1/2" Integrated Aluminium Cup
  • Crankset
    Shimano Ultegra R8100 36x52T w/left side 4iiii Power Meter
  • Shifters
    Shimano ST-8170
  • Cassette
    Shimano Ultegra R8100 11-30t 12-Speed
  • Rear derailleur
    Shimano Ultegra Di2 R8150
  • Front derailleur
    Shimano Ultegra Di2 R8150
  • Chain
    Shimano M8100
  • Handlebar
    Integrated Bar and Stem OC SH-RA10, Road Aero Carbon, Reach 80, Drop 125
  • Brakes
    Shimano R8170 Hydraulic Disc
  • Rotors
    160mm Front /140mm Rear
  • Wheels
    Oquo Road Performance RP45LTD
  • Tyres
    Vittoria Corsa Pro 29-622 TLR wide rim G2.0 OEM HP
  • Front Wheel Axle
    Orbea Thru Axle 12x100mm M12x2 P1 Lite
  • Rear Wheel Axle
    Orbea Thru Axle 12x142mm M12x2 P1 Lite
  • Seatpost
    OC Performance XP10-S Carbon, 27.2mm, Setback 20
  • Saddle
    Fizik Vento Antares R1 Carbon Rail 140mm
  • Handlebar Tape
    Orbea Anti-Slippery/Shock Proof
Sizing Information
Mountain/Leisure Bikes

Rider Height (ft/in)Rider Height (cm)Orbea Mountain Bike Size
4'11" - 5'3"150 - 160 cmXS
5'3" - 5'6"160 - 168 cmS
5'6" - 5'9"168 - 175 cmM
5'9" - 6'0"175 - 183 cmL
6'0" - 6'3"183 - 191 cmXL
6'3" - 6'7"191 - 200 cmXXL

Road/Gravel Bikes

Rider Height (ft/in)Rider Height (cm)Orbea Road Bike Size
4'10" - 5'1"147 - 155 cm47-49cm
5'1" - 5'4"155 - 163 cm49-51cm
5'4" - 5'7"163 - 170 cm51-53cm
5'7" - 5'9"170 - 175 cm53-55cm
5'9" - 6'0"175 - 183 cm55-57cm
6'0" - 6'2"183 - 188 cm57-59cm
6'2" - 6'5"188 - 196 cm59-61cm
6'5" - 6'8"196 - 203 cm61-63cm


Please note that this is a general guideline, and you should always refer to the specific bike's geometry chart to ensure a proper fit. Please visit Orbea for more information
