| COLOUR | Gun metal (matt) | CASSETTE | Shimano LG400, 11-48T, 10 speed |
|---|
| FRAME | 6061-T6 aluminium, multi-shaped tubing; Single Chain Ring (SCR) 1x-specific design; 1.125–1.5in tapered Zero-Stack headtube; full 300mm reamed depth 30.9mm seat tube; Post Mount 180mm disc dropout; SRAM UDH spec derailleur hanger; 12mm x 148mm Boost. | CHAIN | KMC eGlide, 118 links, 10 speed |
|---|
| FORK | Suntour XCR36X, 130mm travel, 44mm offset, Black coating, adjustable compression and rebound, tapered steerer, 110mm x 15mm Boost | CRANKSET | Whyte 155mm length ISIS crank arms, direct mount 36T chainring, narrow wide |
|---|
| REAR SHOCK | N/A | BOTTOM BRACKET | N/A |
|---|
| HEADSET | ZS56 upper / lower headset cups for 1 1/8in upper and 1.5in lower with sealed bearings | SEATPOST | TranzX dropper post, 30.9mm, frame size specific drop (size S 150mm drop; sizes M-XL 170mm drop) |
|---|
| REAR HUB | Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, nine degree micro engagement four pawl, 32 hole, HG freehub | SEAT | Whyte Custom |
|---|
| FRONT HUB | Alloy, 15mm x 110mm Boost spacing, 32 hole | BAR | Whyte 6061 alloy, 30mm rise, 35mm bar bore, 760mm wide |
|---|
| SPOKES | 2.0mm, black stainless, brass nipples | STEM | Whyte alloy, 40mm extension, 35mm bar bore |
|---|
| RIMS | Whyte eMTB, sleeved joint, 30mm internal width, tubeless ready, 32 hole | GRIPS | Whyte Trail lock-on |
|---|
| TYRES | Maxxis Rekon 29 x 2.6in (front and rear, sizes M-XL) / 27.5 x 2.6in (front and rear, size S) | BRAKES FRONT | Tektro M5141 hydraulic disc brake, four piston, 203mm diameter disc rotor |
|---|
| SHIFT LEVERS | Shimano CUES U6000, 10 speed, band on clamp | BRAKES REAR | Tektro M5141 hydraulic disc brake, four piston,180mm diameter disc rotor, Avinox tone wheel incorporated in rotor |
|---|
| FRONT MECH | N/A | BRAKE LEVERS | Tektro M5141 |
|---|
| REAR MECH | Shimano CUES U6000, 10 speed | PEDALS | Fibre reinforced composite platform |
|---|
